Downloads

Spirale-System Downloads
(System software for Spirale 2 & 3 Equipments)
Versions History: doc txt

Only download the version that corresponds to your equipment !
Take another version will lead to malfunction.

Spirale 3 / Vision - Windows 7/10 (Panel-PC)
Date: 10/2022
spirale-system-v8.45.exe

Once download complete, copy the .exe file on a USB stick.
On the equipment, quit the spirale software and open a Windows session (login codes are provided with the equipment).
With windows explorer, select the .exe file on the USB stick and run it.
Follow the instructions and accept default choices.
At the installation end, remove the USB stick, then power off the equipment. You can now power on the equipment as usual.

Spirale 3 - Windows 2000 (PC indus.)
Date: 06/2013
spirale-system-v5.22.zip

Once download complete, you have to extract the zip contents and copy the contents on a USB stick.
On the equipment, quit the spirale software and open a Windows session (login codes are provided with the equipment).
With windows explorer, select the Setup.exe file on the USB stick and run it.
Follow the instructions and accept default choices.
At the installation end, remove the USB stick, then power off the equipment. You can now power on the equipment as usual.

Spirale 2 - Windows 2000 (PC indus.)
Date: 05/2010
spirale-system-v4.81.zip

Spirale 2 - Windows NT (PC indus.)
Date: 01/2006
spirale-system-v3.4.zip

Once download complete, you have to extract the zip contents and burn the contents on a CD-ROM.
On the equipment, quit the spirale software and open a Windows session (login codes are provided with the equipment).
With windows explorer, select the Setup.exe file on the CD-ROM and run it.
Follow the instructions and accept default choices.
At the installation end, remove the CD-Rom, then power off the equipment. You can now power on the equipment as usual.

Desktop versions Downloads
(Software are compatibles Windows XP/Vista/7/8/10)

ProgWin - Profiles Editor
Progwin.zip

VisuWin - Test files Viewer
Visuwin.zip

These software are available in portable version. No installation is required.
Create a new folder in which you will copy the contents of the zip file.
Then run Progwin.exe (profiles editor), or VisuWin.exe (test files Viewer).
